Product Model
EE-SPX843
Selling Points
- 1High Accuracy & Reliability: The EE-SPX843 ensures precise detection with its modulated infrared light and through-beam sensing method.
- 2Wide Voltage Range: Operates from 5 to 24 VDC, providing flexibility in various industrial applications.
- 3Compact Design: Measures just 3.6 mm in slot width, ideal for space-constrained environments.
- 4Durable Construction: Built with PBT casing and IP50 rating for robust performance in harsh conditions.
- 5Easy Installation: Features a connector type connection and panel mount design for straightforward integration.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Connection | Built-in Connector | Housing Material | Plastic |
Light Source | GaAs Infrared LED | Output | NPN |
Sensing Method | Through-beam | Supply Voltage | 5 to 24 VDC |
Type | Photomicro | Body Type | R-shaped |
Max Sensing Distance | 3.6 mm | Operation | Light-ON |
Specifications may be subject to change without notice
