Product Model
BCM/S16.1.1
Selling Points
- 1The BCM/S16.1.1 measures 74 mm x 34 mm x 135 mm, making it perfect for space-constrained applications.
- 2With an output current of 0.50 A DC, this module ensures consistent and reliable operation in building automation systems.
- 3Features pluggable spring terminals for easy cable connection, simplifying the installation process.
- 4Equipped with 16 switchable digital inputs/outputs, suitable for various control applications in building automation.
- 5Designed to work with BAC/S Building Automation Controller KNX, ensuring seamless integration into existing systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Degree of Protection | IP20 | Data Sheet, Technical Information | 9AKK107046A7502 |
Number of Outputs | 16 | Number of Digital Inputs | 16 |
Number of Inputs | Analog (0 ... 10 V / 4 ... 20 mA) 16 | Product Range | KNX |
Manual Operation | No | Number of Batteries | 0 |
Product Net Width | 34 mm | Product Net Height | 135 mm |
Product Net Depth / Length | 74 mm | Product Net Weight | 0.19 kg |
ETIM 9 | EC001419 - PLC digital I/O-module | eClass | V11.0 : 27242204 |
UNSPSC | 32151705 | Object Classification Code | A |
WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Consumer |
Manufacturer ID | 2CDG120064R0011 |
Specifications may be subject to change without notice
