Product Model
BCM/S6.5.5.1
Selling Points
- 1Extension Module for BAC/S KNX Building Automation: Ideal for integrating with BAC/S KNX controllers.
- 24 Analogue Inputs and 2 Analogue Outputs: Supports a wide range of voltage signals.
- 3Voltage Signal Support: Handles signals from 0 V to +10 V, including -2.5 V to +2.5 V and -5 V to +5 V.
- 4Reliable Installation Relay: Ensures stable operation with its installation relay type.
- 5Compact Design: Measuring 74 mm in length, 34 mm in width, and 135 mm in height.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Degree of Protection | IP20 | Data Sheet, Technical Information | 9AKK107046A7504 |
Number of Outputs | 2 | Number of Inputs | Analog (0 ... 10 V / 4 ... 20 mA) 4 |
Product Range | KNX | Manual Operation | No |
Number of Batteries | 0 | Product Net Width | 34 mm |
Product Net Height | 135 mm | Product Net Depth / Length | 74 mm |
Product Net Weight | 0.18 kg | ETIM 9 | EC001420 - PLC analogue I/O-module |
eClass | V11.0 : 27242201 | UNSPSC | 32151705 |
Object Classification Code | A | WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
WEEE B2C / B2B | Business To Consumer | Manufacturer ID | 2CDG120067R0011 |
Specifications may be subject to change without notice
