Product Model
CR-P024TRI1
Selling Points
- 1High-quality cadmium-free contact material for increased mechanical and electrical lifespan.
- 224V DC input and 3A/240V AC Triac output for versatile control options.
- 3Compact dimensions (12.7 mm x 15.7 mm x 29 mm) for space-efficient installations.
- 4Integrated test button for manual actuation and locking of output contacts.
- 5Reliable performance in industrial machine control, control panel, and energy management applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product Net Width | 12.7 mm | Product Net Height | 15.7 mm |
Product Net Depth / Length | 29 mm | Product Net Weight | 0.011 kg |
Function | Pluggable pcb optocoupler CR-P | Rated Control Supply Voltage (Us) | 10 ... 32 V DC |
Output | TRIAC | Output Signal | 275VAC / 3A |
Degree of Protection | IP67 | Standards | IEC/EN 62314 |
Ambient Air Temperature | Operation -20 ... +50 °C Storage -20 ... +70 °C | ETIM 7 | EC001504 - Optocoupler |
ETIM 8 | EC001504 - Optocoupler | ETIM 9 | EC001504 - Optocoupler |
eClass | V11.0 : 27371604 | UNSPSC | 32111705 |
Manufacturer ID | 1SVR405610R4070 |
Specifications may be subject to change without notice
