Product Model
LS30P41-9055
Selling Points
- 1Robust construction for harsh industrial environments.
- 2Meets international standards and certifications.
- 3Customizable options including LED lighting and various contact blocks.
- 4Easy installation and maintenance with tool-free mounting.
- 5Suitable for a variety of industrial settings including cement, food, and beverage industries.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product Net Width | 30 mm | Product Net Height | 116 mm |
Product Net Depth / Length | 45 mm | Product Net Weight | 0.086 kg |
B10d Value | Operations 30 Millions | Conventional Free-air Thermal Current (Ith) | acc. to IEC 60947-5-1, Π= 40 °C 10 A |
Degree of Protection | acc. to IEC 60529 IP65 | Maximum Electrical Switching Frequency | (AC-15) 3600 cycles per hour (DC-13) 3600 cycles per hour |
Mechanical Durability | 10 million | Pilot Duty UL/CSA | A600 Q600 |
Rated Impulse Withstand Voltage (Uimp) | 6 kV | Rated Operational Current AC-15 (Ie) | (24 V) 10 A (240 V) 6 A |
Rated Insulation Voltage (Ui) | acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 400 V | Rated Operational Current DC-13 (Ie) | (24 V) 4 A (110 V) 0.6 A (125 V) 0.55 A (250 V) 0.4 A |
Short-Circuit Protective Devices | gG Type Fuses 10 A | Ambient Air Temperature | Operation -25 ... +70 °C Storage -30 ... +80 °C |
ETIM 7 | EC000030 - End switch | ETIM 8 | EC000030 - End switch |
eClass | V11.0 : 27272601 | UNSPSC | 39121500 |
Manufacturer ID | 1SBV010241R9055 |
Specifications may be subject to change without notice
