ABBTravel switch
Product Model

LS33P12B11

Manufacturer

ABB

Category

Travel switch

Product ID

75998

In Stock
Last updated: 2025/4/28
View Specifications
ABB LS33P12B11

Selling Points

  • 1High Mechanical Durability: Handles up to 30 million operations with mechanically linked contacts.
  • 2Easy Installation: Features three different types of electrical connections and cable lengths for various design specifications.
  • 3Fiber-Glass Reinforced Material: Made of UL-V0 material for enhanced protection and reliability.
  • 4Snap Action Contacts: Includes 1 N.O + 1 N.C snap action contacts for precise operation.
  • 5Compact Design: Measures 30 mm wide, 84 mm high, and 30 mm deep, making it suitable for limited mounting spaces.
Product Details
LS33P12B11
ABB

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Product Net Width
30 mm
Product Net Height
84 mm
Product Net Depth / Length
30 mm
Product Net Weight
0.067 kg
Action Type of the Contact Element (acc. to IEC 60947-5-1)
Snap Action Simultaneous
Actuator Type
steel roller plunger
B10d Value
Operations 30 Millions
Conventional Free-air Thermal Current (Ith)
acc. to IEC 60947-5-1, Θ = 40 °C 10 A
Degree of Protection
acc. to IEC 60529 IP65
Housing Material
Plastic
Maximum Electrical Switching Frequency
(AC-15) 3600 cycles per hour (DC-13) 3600 cycles per hour
Maximum Mounted Auxiliary Contacts
1 NO, 1 NC
Mechanical Durability
15 million
Mounting Type
30 mm (EN 50047)
Number and Type of Bottom Cable Glands
1 x M20x1.5 - Bottom
Pilot Duty UL/CSA
A600 Q600
Rated Impulse Withstand Voltage (Uimp)
6 kV
Rated Operational Current AC-15 (Ie)
(230 V AC) 3.1 A (400 V) NC 4 (24 V) 10 A (130 V) 5.5 A (240 V) 3 A
Rated Insulation Voltage (Ui)
acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 500 V acc. to UL/CSA 600 V
Rated Operational Current DC-13 (Ie)
(24 V) 6 A (110 V) 0.6 A (125 V) 0.55 A (250 V) 0.4 A
Short-Circuit Protective Devices
gG Type Fuses 10 A
Ambient Air Temperature
Operation -25 ... +70 °C Storage -30 ... +80 °C
Object Classification Code
B
ETIM 6
EC000030 - End switch
ETIM 7
EC000030 - End switch
ETIM 8
EC000030 - End switch
eClass
V11.0 : 27272601
UNSPSC
39121500
Manufacturer ID
1SBV012212R1211

Specifications may be subject to change without notice
