Product Model
OVR T2 1N 40-150 P U
Selling Points
- 1Protects against transient overvoltages with a nominal discharge current of 20 kA and a maximum of 40 kA.
- 2Easy integration into modular DIN rail systems, ensuring flexibility and space efficiency.
- 3Meets international standards IEC 61643-1 Ed2 and UL 1449 Ed3 for reliability and safety.
- 4Designed to last up to 20 years, with some units lasting up to 30 years, depending on environmental conditions.
- 5Simple installation in sub-distribution boards near protected equipment for effective surge protection.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Standards | UL 1449 Ed3 | Suitable For | To protect the systems against the transient overvoltage (lightning) |
Rated Voltage (Ur) | 120 V AC | Nominal AC Voltage of the System (Uo) | 120 V |
Voltage Protection Level ( Up) | 1.2 kV (L-N) 1.2 kV (N-PE) 1.2 kV | Maximum Continuous Operating Voltage (Uc) | (L-PE) 175 V |
Rated Service Short-Circuit Breaking Capacity (Ics) | 100 kA | Discharge Current | Nominal (8 / 20 µs) 20 kA I (max, 8 / 20 µs) 40 kA |
Short Circuit Withstand Icc | 100 kA | Arrester Class | II |
Number of Protected Poles | 2 | Number of Poles | 2 |
Number of Conductors | 2 | Position of Neutral Terminals | Right |
Transmission Standard | Optic | Version | Plug-in |
Mounting Type | DIN-Rail | Options Provided | Residential, commercial building. |
Preventive Maintenance Feature | No | Status Indicator | Yes |
Fuse Size | 2 modular spacing | Degree of Protection | IP20 |
Maximum Operating Altitude Permissible | Without Derating 5000 | Maximum Continuous Operating Voltage UL/CSA (MCOV) | (L-PE) 175 V (L-L) - V (L-N) 175 V (N-PE) 175 V |
Maximum Operating Voltage UL/CSA | 175 V | Short-Circuit Current Rating (SCCR) | 200 kA |
Type of Low Voltage Distribution System UL/CSA | Single Phase | Width in Number of Modular Spacings | 2 |
Product Net Width | 35.6 mm | Product Net Height | 90.5 mm |
Product Net Depth / Length | 64.8 mm | Product Net Weight | 0.24 kg |
ETIM 8 | EC000941 - Surge protection device for power supply systems | ETIM 9 | EC000941 - Surge protection device for power supply systems |
WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Business |
CN8 | 85363090 | eClass | V11.0 : 27130805 |
Object Classification Code | 141DBC | Manufacturer ID | 2CTB802342R2000 |
Specifications may be subject to change without notice
