Product Model
S202M-C32UC V
Selling Points
- 1The S202M-C32UC boasts a high inbuilt short-circuit breaking capacity, ensuring reliable protection in various electrical applications.
- 2Designed for both AC and DC applications, this MCB offers flexibility in a wide range of electrical systems.
- 3Meets IEC/EN 60898-1, IEC/EN 60947-2, and UL 1077 standards, ensuring compliance with major international and local regulations.
- 4The compact design makes it easy to integrate into modular DIN rail systems, saving space in electrical panels.
- 5Built with durable materials, the S202M-C32UC withstands operational temperatures from -25°C to +55°C, ensuring long-lasting performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Tripping Characteristic | C | Rated Current (In) | 32 A |
Number of Poles | 2 | Product Net Width | 35 mm |
Product Net Height | 85 mm | Product Net Depth / Length | 69 mm |
Product Net Weight | 0.250 kg | ETIM 8 | EC000042 - Miniature circuit breaker (MCB) |
ETIM 9 | EC000042 - Miniature circuit breaker (MCB) | WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
WEEE B2C / B2B | Business To Business | CN8 | 8536200000 |
eClass | V11.0 : 27141901 | Object Classification Code | F |
Manufacturer ID | 2TAZ113200R0324 |
Specifications may be subject to change without notice
