Product Model
B810-W
Selling Points
- 1The B810-W features a compact modular design, integrating major dimensions for space-saving assembly.
- 2Constructed with aluminum for the body and resin for the cover, providing light weight and durability.
- 3Compatible with 6000 and 8000 Series models, offering flexibility in system configurations.
- 4Designed with two holes on the top and bottom for easy wall mounting, ensuring secure device fixation.
- 5Equipped with CKD's original chemical fiber structure, reducing clogging and extending element life significantly.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model no. | B810-W | Applicable model | 6000 Series 8000 Series |
A | 70mm | B | 50mm |
C | 15mm | D | 150mm |
E | 9.0mm | F | 14mm |
G | 27.000mm | H | 37mm |
I | 8.0mm | J | AS568-127 |
K | 65mm | Infotext | https://www.ckd.co.jp/kiki/en/product/detail/845/B%E2%80%BB%E2%80%BB0%E3%83%BBC%E2%80%BB000-J%E2%80%BB00-W?t=list&cid=66&sid=0 |
Specifications may be subject to change without notice
