CKD CorporationFittings/tubes
Product Model

GWJT3-M3-D

Manufacturer

CKD Corporation

Category

Fittings/tubes

Product ID

51589

In Stock
Last updated: 2025/5/1
View Specifications
CKD Corporation GWJT3-M3-D

Selling Points

  • 1High reliability due to Japanese-made key parts.
  • 2Flexible and durable design with flame-resistant materials.
  • 3Easy electrical connection and maintenance with DIN terminal box.
  • 4Wide range of fluid types and temperatures supported.
  • 5Compact and lightweight aluminum body with 20% weight reduction.
Product Details
GWJT3-M3-D
CKD Corporation

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Model No.
GWJT3-M3-D
Compatible tube O.D. φ
3.2mm
Thread
M3x0.5
Hex
8mm
L1
13.0mm
L2
15.5mm
A
2.4mm
B
12.5mm
C
8.5mm
Min. bore size
1.2mm
Eff. X-sectional area
0.9mm^2
Weight
4.4g

Specifications may be subject to change without notice
