Product Model
aen-s-6-5-i
Selling Points
- 1The Festo AEN-S-6-5-I compact air cylinder is designed for applications where space is critical, offering a compact and lightweight solution.
- 2With a stroke of 5 mm and a piston diameter of 6 mm, this cylinder is perfect for short-stroke movements and precise control.
- 3The cylinder features an internal thread on the piston rod end, providing versatility in mounting options.
- 4The AEN-S series includes elastic cushioning options, ensuring smooth operation and reducing wear on the cylinder.
- 5The magnetic piston allows for position sensing, enhancing the cylinder's accuracy and reliability in various applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Stroke | 5mm | Piston diameter | 6 mm |
Cushioning | No cushioning | Mounting position | Any |
Mode of operation | Pushing | Piston rod end | Internal thread |
Structural design | Piston Piston rod | Symbol | 00991200 |
Variants | Piston rod at one end | Operating pressure | 2.5bar 8bar |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] | Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B2-L |
Ambient temperature | -10°C 60°C | Impact energy in the end positions | 0.006J |
Theoretical force at 6 bar, retracting | 4N | Theoretical force at 6 bar, advancing | 13N |
Moving mass | 1.5g | Product weight | 9.2g |
Type of mounting | With through-hole | Pneumatic connection | M3 |
Note on materials | RoHS-compliant | Cover material | Wrought aluminum alloy |
Material of dynamic seals | NBR TPE-U(PU) | Housing material | Wrought aluminum alloy Anodized |
Piston rod material | High-alloy stainless steel | Manufacturer ID | 4984929 |
Specifications may be subject to change without notice
