Product Model
crvzs-0.4
Selling Points
- 1The Festo CRVZS-0.4 air reservoir is designed to store compressed air, providing a stable volume of 0.4 liters to smooth out pressure fluctuations in pneumatic systems.
- 2Made from high-alloy stainless steel, this air reservoir ensures high corrosion resistance and durability, making it suitable for various industrial applications.
- 3The CRVZS-0.4 features a G1/4 pneumatic connection, allowing for easy integration into new or existing high-pressure air systems, enhancing system efficiency.
- 4Operating within a temperature range of -10°C to 100°C, this air reservoir can handle a wide range of ambient conditions, ensuring reliable performance.
- 5With a maximum operating pressure of 16 bar and a minimum operating pressure of -0.95 bar, the CRVZS-0.4 is versatile and adaptable to various pneumatic system requirements.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Volume | 0.4 l | Mounting position | Any |
Conforms to standard | AD 2000 | Symbol | 00991528 |
Operating pressure | -13.78psi 232psi | Certification | CRN German Technical Control Board (TüV) |
Certificate issuing authority | TSSACRN0H17477.5C | Operating medium | Compressed air as per ISO 8573-1:2010 [-:-:-] Nitrogen |
Corrosion resistance class (CRC) | 3 - High corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
For use in the food industry | See supplementary material information | Temperature of medium | -10°C 100°C |
Ambient temperature | -10°C 100°C | Max. tightening torque for connecting thread | 23Nm |
Product weight | 543g | Type of mounting | Fixing clips |
Pneumatic connection | G1/4 | Note on materials | RoHS-compliant |
Air reservoir material | High-alloy stainless steel | Fixing clips material | High-alloy stainless steel |
Manufacturer ID | 160234 |
Specifications may be subject to change without notice
