Product Model
esh-ha-2-qs
Selling Points
- 1Compact Design: The Festo ESH-HA-2-QS suction cup holder is designed for vertical mounting with a 4mm suction cup diameter.
- 2Robust Construction: Made from NBR material seals and available in various retaining bracket materials including aluminum, nickel-plated brass, POM, tempered steel, and high-alloy steel.
- 3Low Corrosion Resistance: Offers low corrosion stress resistance class CRC 1 for durability in harsh environments.
- 4Versatile Mounting: Equipped with a via lock nut type of mounting for secure attachment to your vacuum system.
- 5Compliant with Standards: Meets RoHS compliance and VDMA24364-A1-L LABS (PWIS) conformity for environmental and safety standards.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Nominal width | 2mm | Volume | 0.501cm3 |
Mounting position | Any | Structural design | Vacuum connection at top |
Classification of suction cup holder | Size 2 | Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] |
Corrosion resistance class (CRC) | 1 - Low corrosion stress | LABS (PWIS) conformity | VDMA24364-A1-L |
Ambient temperature | 0°C 60°C | Product weight | 12g |
Type of mounting | With lock nut | Suction cup mounting | Diameter 4 mm |
Vacuum connection | QS-6 | Note on materials | RoHS-compliant |
Seals material | NBR | Retaining bracket material | Aluminum Brass, nickel-plated POM Tempered steel High-alloy steel |
Manufacturer ID | 189195 |
Specifications may be subject to change without notice
