Product Model
hgl-3/8-qs-8
Selling Points
- 1The Festo HGL-3/8-QS-8 piloted check valve ensures one-way flow control in pneumatic systems, preventing backflow and maintaining system integrity.
- 2This valve is actuated pneumatically, allowing for precise control over the flow of compressed air, making it ideal for various industrial applications.
- 3Built with high-quality materials, including copper-free and PTFE-free components, the valve is RoHS compliant and resistant to moderate corrosion stress.
- 4The valve can be mounted in any position, offering flexibility in system design and installation. It also features a screw-in design with a male thread for easy installation.
- 5With a standard flow rate of 1200 l/min and a nominal flow rate of 830 l/min, the Festo HGL-3/8-QS-8 ensures efficient operation within a wide range of operating pressures (0.5 to 10 bar).
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Valve function | Unlockable non-return function | Pneumatic connection 1 | QS-8 |
Pneumatic connection 2 | G3/8 | Pilot air port 21 | G1/4 |
Actuation type | Pneumatic | Type of mounting | Screw-in With external thread |
Operating pressure | 0.5bar 10bar | Pilot pressure MPa | 0.1MPa 1MPa |
Pilot pressure | 1bar 10bar | Pilot pressure psi | 14.5psi 145psi |
Ambient temperature | -10°C 60°C | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
Maritime classification | See certificate | Mounting position | Any |
Symbol | 00991456 | Standard flow rate 1->2 (6-0) | 1200l/min |
Standard nominal flow rate 1->2 (6-5) | 830l/min | Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B2-L |
Cleanroom class | Class 4 according to ISO 14644-1 | Storage temperature | -10°C 60°C |
Temperature of medium | -10°C 60°C | Pilot medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
Nominal tightening torque | 12.5Nm | Tolerance for nominal tightening torque | ± 10% |
Product weight | 54.7g | Note on materials | RoHS-compliant |
Seals material | NBR | Hollow bolt material | Wrought aluminum alloy Anodized |
Releasing ring material | POM | Non-return collar material | NBR |
Swivel joint material | Die-cast zinc | Manufacturer ID | 530043 |
Specifications may be subject to change without notice
