Product Model
ms4n-lr-1/4-d6-as
Selling Points
- 1The Festo MS4N-LR-1/4-D6-AS pressure regulator offers precise pressure regulation, ensuring consistent performance in industrial automation applications.
- 2This pressure regulator features a rotary knob with detent for easy actuator lock, providing reliable control and minimizing manual errors.
- 3With a service life of 20 million cycles, the MS4N-LR-1/4-D6-AS is a well-tried component suitable for safety-related applications, ensuring long-term reliability.
- 4The MS4N-LR-1/4-D6-AS is designed to withstand various environmental conditions, including vibration and shock tests, ensuring it can operate in demanding industrial settings.
- 5This pressure regulator is part of the MS series, known for its direct control and versatility in mounting positions, making it easy to integrate into various automation systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | 4 | Series | MS |
Actuator lock | Rotary knob with detent can be closed with accessories | Mounting position | Any |
Structural design | Directly controlled diaphragm regulator | Controller function | Outlet pressure constant With secondary exhausting With return flow function |
Symbol | 00991558 | Pressure gauge | with pressure gauge |
Operating pressure | 0.8bar 14bar | Pressure regulation range | 0.3bar 7bar |
Max. pressure hysteresis | 3.625psi | Standard nominal flow rate | 1800l/min |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas | Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Storage temperature | -10°C 60°C | For use in the food industry | See supplementary material information |
Temperature of medium | -10°C 60°C | Ambient temperature | -10°C 60°C |
Product weight | 225g | Type of mounting | Optionally: Front panel mounting Line installation With accessories |
Pneumatic connection 1 | 1/4 NPT | Pneumatic connection 2 | 1/4 NPT |
Note on materials | RoHS-compliant | Material of sub-base | Die-cast aluminum |
Material of operator panel | PA POM | Seals material | NBR |
Housing material | Die-cast aluminum | Diaphragm material | NBR |
Manufacturer ID | 531422 |
Specifications may be subject to change without notice
