Product Model
necu-l3g8-c1-is
Selling Points
- 1Supports up to 100 connections.
- 2Easy and secure electrical connections.
- 3Operates between 0-30 V DC.
- 4Handles up to 12 A at 40°C.
- 5Made from RoHS-compliant polyamide with tin-plated copper alloy contacts.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Explosion prevention and protection | Observe the information on the certificate Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) | Contact durability | 100 |
Mounting position | Any | Product weight | 33g |
Electrical connection | 8-pin Spring-loaded terminal Plug, straight | DC operating voltage range | 0V 30V |
Current rating at 40° C | 12A | Surge resistance | 4kV |
Connection cross section | 0.2mm2 2.5mm2 | Ambient temperature | -40°C 85°C |
LABS (PWIS) conformity | VDMA24364-B2-L | Note on materials | RoHS-compliant |
Contamination level | 3 | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
Housing material | PA | Housing colour | Blue |
Material of pin contacts | Copper alloy Tin-plated | Manufacturer ID | 565711 |
Specifications may be subject to change without notice
