Product Model
necu-l3g8-c2
Selling Points
- 1100 frequency of connection for versatile use.
- 2Optional mounting position for flexible installation.
- 34KV immunity to surge for reliable operation.
- 48-pin electrical connection with screw terminal.
- 5RoHS-compliant materials for environmental safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Contact durability | 100 | Mounting position | Any |
Product weight | 56g | Electrical connection | 8-pin Screw terminal Plug, straight |
DC operating voltage range | 0V 30V | Current rating at 40° C | 12A |
Surge resistance | 4kV | Connection cross section | 0.2mm2 2.5mm2 |
Ambient temperature | -40°C 85°C | LABS (PWIS) conformity | VDMA24364-B2-L |
Note on materials | RoHS-compliant | Contamination level | 3 |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | Housing material | PA |
Housing colour | Black | Material of pin contacts | Copper alloy Tin-plated |
Manufacturer ID | 565710 |
Specifications may be subject to change without notice
