Product Model
sd-sub-d-st25
Selling Points
- 1The Festo SD-SUB-D-ST25 connector ensures a secure and reliable electrical connection with its 25-pin Sub-D plug, making it perfect for valve manifolds and industrial applications.
- 2This connector can be mounted with a through-hole, offering flexibility in installation and compatibility with various mounting positions.
- 3The SD-SUB-D-ST25 supports a DC operating voltage range of up to 250 V and an AC operating voltage range of up to 250 V, ensuring it can handle a wide range of electrical requirements.
- 4Made from high-quality materials, including PA housing and NBR seals, this connector is designed to withstand ambient temperatures from -20°C to 80°C and is RoHS-compliant.
- 5The gold-plated copper alloy pin contacts provide excellent conductivity and durability, ensuring long-lasting performance in demanding industrial environments.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Type of mounting | With through-hole | Mounting position | Any |
Product weight | 51g | Electrical connection | 25-pin Plug Sub-D |
DC operating voltage range | 250V | Operating voltage range AC | 250V |
Current rating | 5A | Cable fitting | Pg11 |
Approved cable diameter | 7mm 12mm | Degree of protection | IP65 |
Ambient temperature | -20°C 80°C | LABS (PWIS) conformity | VDMA24364-B2-L |
Note on materials | RoHS-compliant | Housing material | PA |
Seals material | NBR | Material of pin contacts | Copper alloy Gold-plated |
Manufacturer ID | 527522 |
Specifications may be subject to change without notice
