Product Model
smpo-8e
Selling Points
- 1The Festo SMPO-8E proximity sensor is designed for T-slot compatibility, ensuring seamless integration with all Festo cylinders that have T-slots.
- 2This sensor operates within a wide temperature range of -15°C to +60°C and can withstand pressures from 2 to 8 bar, making it suitable for various industrial applications.
- 3The SMPO-8E features a magnetic measuring principle and provides optical switching status indication, ensuring accurate and reliable sensing.
- 4With an IP65 rating, the sensor is protected against dust and water, ensuring durability in harsh environments.
- 5The sensor is compatible with compressed air to ISO 8573-1:2010 [6:4:4] and is RoHS-compliant, meeting stringent environmental and safety standards.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Design | for T-slot | Symbol | 00991600 |
Explosion prevention and protection | Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) | Note on materials | RoHS-compliant |
Measuring principle | Magnetic | Operating pressure | 2bar 8bar |
Operating medium | Compressed air as per ISO 8573-1:2010 [6:4:4] | Information on operating and pilot media | Operation with oil lubrication not possible |
Ambient temperature | -15°C 60°C | Reproducibility of switching value | +/- 0.2 mm |
On time | 22ms | Switch-off time | 52ms |
Type of mounting | With through-hole With accessories Can be inserted in slot from above | Valve function | 3/2 |
Pneumatic connection | M5 | Product weight | 11g |
Housing material | Aluminum PA Anodized High-alloy stainless steel | Switching status indication | Optical |
Degree of protection | IP65 | LABS (PWIS) conformity | VDMA24364-B2-L |
Manufacturer ID | 178563 |
Specifications may be subject to change without notice
