Product Model
vabv-s2-1hs-g38-cb-t2
Selling Points
- 1CE Marking Compliance: Meets EU low voltage directive and UKCA marking standards.
- 2Corrosion Resistance: Classified as CRC 0 - No corrosion stress, ensuring long-lasting performance.
- 3Durable Construction: Made from die-cast aluminum for robustness and reliability.
- 4Pneumatic Connections: Equipped with G3/8 pneumatic connections for easy integration.
- 5Compact Design: Measures 43 mm in width, perfect for space-efficient installations.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 43mm | CE marking (see declaration of conformity) | As per EU low voltage directive |
UKCA marking (see declaration of conformity) | To UK instructions for electrical equipment | Corrosion resistance class (CRC) | 0 - No corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Product weight | 330g |
Pneumatic connection 2 | G3/8 | Pneumatic connection 4 | G3/8 |
Note on materials | RoHS-compliant | Plate material | Die-cast aluminum |
Manufacturer ID | 8068154 |
Specifications may be subject to change without notice
