Product Model
vavc-f12-scc-20-p
Selling Points
- 1The Festo VAVC-F12-SCC-20-P is a high-performance angle seat valve designed for precise control and reliability in various industrial applications.
- 2This valve features a nominal width of 20 mm and is constructed with high-alloy stainless steel for durability and resistance to corrosion.
- 3The VAVC-F12-SCC-20-P is suitable for use with vapor, hydraulic fluid, inert gas, mineral oil, water, and filtered compressed air, ensuring versatility in different environments.
- 4The valve operates within a temperature range of -30 °C to 200 °C, making it suitable for a wide range of industrial processes.
- 5The Festo VAVC-F12-SCC-20-P is ATEX certified for use in hazardous environments, ensuring safety and compliance with industry standards.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Nominal width DN | 20 | Explosion prevention and protection | Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) |
LABS (PWIS) conformity | VDMA24364 zone III | Medium | Vapor Hydraulic fluid based on mineral oil Inert gas Mineral oil Water Filtered compressed air, 200 μm filter mesh Neutral liquids |
Information on medium | Gaseous media are only permitted with inflow via valve seat. | Temperature of medium | 100°C 230°C |
Ambient temperature | 0°C 60°C | Storage temperature | -10°C 60°C |
Mounting position | Any | Product weight | 363g |
Note on materials | RoHS-compliant | Cover material | High-alloy stainless steel |
Spindle seal material | PTFE | Seat seal material | PEEK |
Manufacturer ID | 8201222 |
Specifications may be subject to change without notice
