Product Model

FLKM-D50 SUB/S/MKKDS

Manufacturer

Phoenix Contact

Category

Unclassified

Product ID

18094

In Stock
Last updated: 2025/5/1
View Specifications
Phoenix Contact FLKM-D50 SUB/S/MKKDS

Selling Points

  • 1High-Quality Connectivity: Reliable 50-position D-SUB pin strip for secure connections.
  • 2Spring-Cage Connection: Easy and secure connection technology for efficient operations.
  • 3DIN Rail Mounting: Versatile mounting options for easy integration into industrial systems.
  • 4Functional Insulation: Meets IEC 60807-2 standards for functional insulation and safety.
  • 5Wide Operating Range: Operates within -20°C to 50°C ambient temperature range, ensuring durability in various environments.
Product Details
FLKM-D50 SUB/S/MKKDS
Phoenix Contact

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Product type
Interface module
Number of positions
50
Overvoltage category
II
Pollution degree
2
Nominal voltage U
125 V AC/DC
Max. current carrying capacity per branch
2.5 A 1.5 A (with even load on all branches)
Max. total current of voltage supply
2.5 A (per contact)
Rated insulation voltage
125 V
Rated surge voltage
1.2 kV (Functional insulation)
Connection in acc. with standard
IEC / EN
Connection method
Screw connection
Stripping length
8 mm
Screw thread
M3
Conductor cross section rigid
0.2 mm² ... 4 mm²
Conductor cross section flexible
0.2 mm² ... 2.5 mm²
Conductor cross section AWG
24 ... 12
Connection method
D-SUB pin strip
Number of positions
50
Status display
no
Status display present
No
Width
146.3 mm
Height
77 mm
Depth
58.5 mm
Color
green (RAL 6021)
Housing insulation material
PVC
Degree of protection
IP20
Ambient temperature (operation)
-20 °C ... 50 °C
Ambient temperature (storage/transport)
-20 °C ... 70 °C
Standards/regulations
IEC 60664 DIN EN 50178
Mounting type
DIN rail mounting
Assembly note
in rows with zero spacing
Mounting position
any
Notes on operation
For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met.

Specifications may be subject to change without notice
