Product Model
1606-XLE240EH
Selling Points
- 11. Efficient Performance
- 2-: The 1606-XLE240EH boasts an efficiency of up to 91.6%, ensuring minimal energy loss and optimal performance in industrial environments.;
- 32. Auto-Select Input
- 4-: With auto-select input, this power supply can operate seamlessly on a wide range of input voltages (100-240V AC), making it versatile for global installations.;
- 53. Low Inrush Current
- 6-: Designed with low inrush current, the 1606-XLE240EH reduces the risk of power surges and ensures a smooth startup, extending the lifespan of connected devices.;
- 74. Superior Temperature Rating
- 8-: Operating within a wide temperature range of -25°C to +70°C, this power supply maintains its performance even in harsh industrial conditions, reducing the need for derating.;
- 95. Reliability and Durability
- 10-: Built with high-quality components and designed to withstand rigorous industrial environments, the 1606-XLE240EH offers a long lifespan and minimal downtime, ensuring continuous operation in critical applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Dimension Unit | CM | Weight Unit | KG |
Stock Status | NON_STOCKED | Dimension Length | 15.24 |
Dimension Width | 13.97 | Lead Time | 5 |
Dimension Height | 6.35 | Quick Turnaround | false |
Preferred Availability | false | Repairable | NOT_REPAIRABLE |
Weight | 0.68 | Lifetime, min | 120 kh (+40 °C) |
Operating temperature | -25 °C | Ripple and noise, max | 50 mV |
Wall mounting possible | Yes | MTBF | 661 kh (+40 °C, SN29500) |
Degree of protection (IP) | IP20 | Width | 39 mm |
Direct mounting possible | No | Depth | 117 mm |
Height | 124 mm | Stabilized | Yes |
Rail mounting possible | Yes | Output voltage stabilized | Yes |
Input inrush current | 6 A/9 A | Efficiency | 95.2 % typical |
Derating | 6 W/°C | Power losses | 12.1 W typical |
External input fuse, min | B-6 A or C-6 A | Output current range | 10 to 8.6 A |
Power factor | 0.97 typical | Connection terminals | Push-in |
Input inrush current limiter | Active | DC OK relay contact | Yes |
Power reserves | 20 % | Rated supply voltage at DC | 110 V |
Rated supply voltage at AC 60 Hz | 100 V | Rated supply voltage at AC 50 Hz | 100 V |
1st secondary output voltage | 24 V | Voltage type of supply voltage | AC/DC |
Power output | 240 W | Nominal value output current 1 | 10 A |
Max. output current 1 | 10 A | Secondary voltage adjustable | Yes |
Nominal value output voltage 1 | 24 V |
Specifications may be subject to change without notice
