Product Model
1606-XLE480FP
Selling Points
- 11. High Efficiency: The 1606-XLE480FP operates at 96.3% efficiency, minimizing energy waste and reducing heat generation, ensuring reliable performance in various environments.;
- 22. Power Reserve: With a 20% power reserve, this power supply can handle temporary surges and maintain output voltage stability, even at elevated temperatures up to +45°C.;
- 33. Low Electromagnetic Emission: Designed with low electromagnetic emission, the 1606-XLE480FP minimizes interference with other electronic devices, making it suitable for applications requiring high signal integrity.;
- 44. DC-OK Relay Contact: The DC-OK relay contact provides a reliable indication of the power supply's operational status, ensuring that the system can be safely shut down or restarted as needed.;
- 55. Parallel Operation Capability: The power supply can be paralleled to increase output power, allowing for load sharing and redundancy in critical applications. This feature ensures continuous operation even in case of a single unit failure.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Dimension Unit | CM | Weight Unit | KG |
Stock Status | STOCKED | Dimension Length | 14.986 |
Dimension Width | 14.224 | Lead Time | 73 |
Dimension Height | 6.604 | Quick Turnaround | false |
Preferred Availability | false | Repairable | NOT_REPAIRABLE |
Weight | 2.016 | Lifetime, min | 110 kh (+40 °C) |
Operating temperature | -25 °C | Ripple and noise, max | 50 mV |
Wall mounting possible | Yes | MTBF | 540 kh (+40 °C, SN29500) |
Type of electric connection | Screw connection | Degree of protection (IP) | IP20 |
Width | 48 mm | Direct mounting possible | No |
Depth | 127 mm | Height | 124 mm |
Stabilized | Yes | Rail mounting possible | Yes |
Output voltage stabilized | Yes | Input inrush current | 10 A/4.5 A |
Efficiency | 96.3 % typical | Derating | 12 W/°C |
Power losses | 18.4 W typical | External input fuse, min | B-10 A or C-10 A |
Output current range | 10 to 8.6 A | Power factor | 0.98 typical |
DC OK relay contact | Yes | Power reserves | 20 % |
Rated supply voltage at DC | 110 V | Rated supply voltage at AC 60 Hz | 100 V |
Rated supply voltage at AC 50 Hz | 100 V | 1st secondary output voltage | 48 V |
Voltage type of supply voltage | AC/DC | Power output | 480 W |
Nominal value output current 1 | 10 A | Max. output current 1 | 10 A |
Secondary voltage adjustable | Yes | Nominal value output voltage 1 | 48 V |
Specifications may be subject to change without notice
