Product Model

BMXDDO3202

Manufacturer

schneider

Category

PLC/PAC and Controllers

Product ID

29566

In Stock
Last updated: 2025/5/1
View Specifications
schneider BMXDDO3202

Selling Points

  • 1High-Performance Discrete Input: Equipped with 32 isolated discrete input channels for robust performance in industrial settings.
  • 2Wide Sensor Compatibility: Compatible with 2-wire and 3-wire proximity sensors conforming to IEC 60947-5-2 and IEC 61131-2 Type 1 standards.
  • 3Enhanced Safety Features: Offers insulation resistance exceeding 10 MOhms at 500 V DC, ensuring electrical integrity and safety.
  • 4Reliable Operation: Boasts a Mean Time Between Failures (MTBF) rating of 696,320 hours, ensuring long-lasting reliability.
  • 5Versatile Environmental Operation: Operates from 0°C to 60°C, suitable for various industrial environments with IP20 protection against solid objects and dust.
Product Details
BMXDDO3202
schneider

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Range of Product
Modicon X80
Product or Component Type
Discrete output module
Discrete output number
32 EN/IEC 61131-2
Discrete output type
Solid state
Discrete output logic
Positive
Discrete output voltage
12...24 V 10.8...30 V DC
Discrete output current
0.5 A
Current per channel
0.55 A
Maximum current per module
17.6 A
Maximum leakage current
0.1 mA at state 0
Maximum voltage drop
<1.2 V at state 1
Insulation resistance
> 10 MOhm 500 V DC
Power dissipation in W
4.8 W
Response time on output
0.3 ms
Paralleling of outputs
Yes : 3 maximum
Typical current consumption
56 mA 3.3 V DC
MTBF reliability
833000 H
Protection type
External fuse reverse polarity protection<br /> short-circuit protection<br /> overload protection<br /> overvoltage protection
Output overload protection
With electronic circuit breaker 1.5 In < Id < 2 In<br />With current limiter
Output overvoltage protection
With transil diode
Output short-circuit protection
With external fuse
Reverse polarity protection
Reverse mounted diode
Voltage detection threshold
< 14 V DC preactuator fault<br />> 18 V DC preactuator at state 0
Maximum tungsten load
6 W 24 V<br />3 W 12 V
Switching frequency
0.5/LI² Hz
Load impedance ohmic
> 54.54 Ohm
Status LED
1 LED (Green) module operating (RUN)<br />1 LED per channel (Green) channel diagnostic<br />1 LED (Red) module error (ERR)<br />1 LED (Red) module I/O
Net Weight
5.009 oz (142.01 g)
IP Degree of Protection
IP20
Directives
2014/35/EU - low voltage directive<br />2014/30/EU - electromagnetic compatibility
Dielectric strength
1780 V AC 50/60 Hz 1 minute, output/ground<br /> 1 minute, output/internal logic
Vibration resistance
3 gn
Shock resistance
30 gn
Ambient Air Temperature for Storage
-40…185 °F (-40…85 °C)
Ambient Air Temperature for Operation
32…140 °F (0…60 °C)
Relative humidity
5…95 % 131 °F (55 °C) without condensation
Operating altitude
0...6561.68 ft (0...2000 m)<br />2000...5000 m with derating factor

Specifications may be subject to change without notice
