Product Model
TM1SHTCC4
Selling Points
- 1High reliability and durability for long-lasting performance.
- 2Efficient power management with advanced circuitry.
- 3Compact design for easy installation in various applications.
- 4Robust protection against overcurrent, overvoltage, and short circuits.
- 5Compatible with a wide range of industrial and commercial systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon M171/M172 | accessory / separate part category | Measurement accessory |
accessory / separate part type | Probe | Device mounting | Wall mounted |
Mounting Support | Mounting box | [Us] rated supply voltage | 9...28 V AC<br />9...40 V DC |
Maximum Power Consumption | 50 mA | Output type | Current 4...20 mA +/- 3 % RH<br />Current 4...20 mA -40…140 °F (-40…60 °C) +/- 1 °C |
Product Specific Application | Humidity control | Electrical connection | Screw-clamp terminals |
Fixing Mode | 2 fixing points | Width | 3.9 in (100 mm) |
Height | 4.8 in (122 mm) | Depth | 2.0 in (50.5 mm) |
Net Weight | 0.31 lb(US) (0.14 kg) | IP Degree of Protection | IP65 |
Ambient Air Temperature for Operation | -40…140 °F (-40…60 °C) | Ambient Air Temperature for Storage | -40…158 °F (-40…70 °C) |
Relative humidity | 0…100 % | Pollution degree | 2 |
Overvoltage category | I | Product Certifications | CE<br />cULus<br />EAC<br />UKCA |
Specifications may be subject to change without notice
