schneiderPushbuttons, Switches, Pilot Lights, Control Stations and Joysticks
Product Model

ZB6DW4

Manufacturer

schneider

Category

Pushbuttons, Switches, Pilot Lights, Control Stations and Joysticks

Product ID

27131

In Stock
Last updated: 2025/4/28
View Specifications
schneider ZB6DW4

Selling Points

  • 1IP65 Protection: Durable and water-resistant, ensuring reliable operation in various environments.
  • 2Spring Return Mechanism: Automatically returns to its original position after actuation, enhancing user experience.
  • 3Durable Plastic Construction: Built with high-quality plastic for long-lasting performance and resistance to wear.
  • 4Easy Installation: Quickly mounts in 16mm diameter holes, simplifying installation processes.
  • 5Illuminated Red Push Button: Clearly visible red illumination for enhanced visibility in dark environments.
Product Details
ZB6DW4
schneider

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Range of Product
Harmony XB6
Product or Component Type
Head for illuminated push-button
Product Compatibility
Integral LED
Device short name
ZB6
Bezel material
Plastic
Mounting diameter
0.6 in (16 mm)
Sale per indivisible quantity
1
Shape of signaling unit head
Rectangular
Type of operator
spring return
Operator profile
Red flush, unmarked
CAD overall width
0.9 in (24 mm)
CAD overall height
0.7 in (18 mm)
CAD overall depth
1.3 in (33 mm)
Net Weight
0.035 lb(US) (0.016 kg)
Protective treatment
TC
Ambient Air Temperature for Storage
-40…158 °F (-40…70 °C)
Ambient Air Temperature for Operation
-13…158 °F (-25…70 °C)
Electrical shock protection class
Class II IEC 61140
IP degree of protection
IP65 IEC 60529
NEMA degree of protection
NEMA 13 UL 50<br />NEMA 4 UL 50<br />NEMA 4X UL 50<br />NEMA 4 CSA C22.2 No 94<br />NEMA 4X CSA C22.2 No 94<br />NEMA 13 CSA C22.2 No 94
Standards
EN/IEC 60947-5-5<br />JIS C8201-5-1<br />CSA C22.2 No 14<br />JIS C 852<br />UL 508<br />EN/IEC 60947-5-1<br />EN/IEC 60947-1<br />JIS C8201-1
Product Certifications
CCC<br />GOST<br />CSA<br />UL
Vibration resistance
+/- 3 mm 2…500 Hz)IEC 60068-2-6<br />5 gn 2…500 Hz)IEC 60068-2-6
Shock resistance
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27<br />50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
