Product Model
ZBE5053
Selling Points
- 1Built to withstand harsh industrial environments with a robust black color.
- 2Measuring 43 mm W x 100 mm D x 73 mm H for precise fitment.
- 3Suitable for use with multiple contact blocks, including ZBE5013, ZBE202, and more.
- 4Constructed from premium materials ensuring long-lasting performance.
- 5Simple mounting process for quick setup in industrial settings.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Harmony XB4<br />Harmony XB5 | Product or Component Type | Contact block |
Device short name | ZBE | Sale per indivisible quantity | 1 |
IP degree of protection | IP20 IEC 60529 | Contact operation | Slow-break |
Contact block type | Double | Contacts usage | High power switching contacts |
Connections - terminals | Faston connector 1 x 6.35 mm<br />Faston connector 2 x 2.8 mm | Net Weight | 0.071 lb(US) (0.032 kg) |
Positive opening | With | Mechanical durability | 10000000 cycles |
Short-circuit protection | 10 A cartridge fuse gG EN/IEC 60947-5-1 | [Ith] conventional free air thermal current | 10 A EN/IEC 60947-5-1 |
[Ui] rated insulation voltage | 300 VEN 60947-1 | [Uimp] rated impulse withstand voltage | 6 kV EN 60947-1 |
[Ie] rated operational current | 1.1 A 125 V, DC-13, P300 EN/IEC 60947-5-1 | Mounting of block | Front mounting |
Electrical composition code | C15 1) | Ambient Air Temperature for Storage | -40…158 °F (-40…70 °C) |
Ambient Air Temperature for Operation | -40…158 °F (-40…70 °C) | Vibration resistance | 5 gn 2…500 Hz)IEC 60068-2-6 |
Shock resistance | 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27<br />50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 |
Specifications may be subject to change without notice
