schneiderPushbuttons, Switches, Pilot Lights, Control Stations and Joysticks
Product Model

ZBYLEG501000

Manufacturer

schneider

Category

Pushbuttons, Switches, Pilot Lights, Control Stations and Joysticks

Product ID

28779

In Stock
Last updated: 2025/5/2
View Specifications
schneider ZBYLEG501000

Selling Points

  • 1Robust Construction: Withstands harsh environments for reliable performance.
  • 2Quick Assembly: Easy and fast installation with various connection types.
  • 3Customizable: Compatible with screw clamp, connector, Faston connector, spring terminal, or printed circuit board.
  • 4Eco-Friendly Packaging: Made with recycled cardboard to reduce environmental impact.
  • 5Comprehensive Compatibility: Designed for use with control and signaling units in various industrial settings.
Product Details
ZBYLEG501000
schneider

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Product or Component Type
Legend panel
accessory / separate part category
Marking accessories
Material
Plastic
Device Composition
Blank panel
Accessory / separate part destination
Ø 16 mm control and signalling units<br />Ø 22 mm control and signalling units<br />Ø 30 mm control and signalling units<br />For standard head
Range Compatibility
Harmony XB4<br />Harmony XB5<br />Harmony XB6<br />Harmony 9001K
Legend holder size
500 x 100
Marking
unmarked
Net Weight
0.066 lb(US) (0.030 kg)
Standards
ISO 21702<br />ISO 22196:2011

Specifications may be subject to change without notice
