Product Model
GRTE18S-N1117
Selling Points
- 1High Precision Sensing: Detects objects with high accuracy, suitable for various industrial applications.
- 2Wide Sensing Range: Operates from 3 mm to 115 mm, ensuring versatility in different environments.
- 3Compact Design: Measuring 18 mm x 18 mm x 38.1 mm, perfect for space-constrained setups.
- 4Reliable Performance: Features a durable plastic housing with an IP67 rating for protection against dust and water.
- 5Easy Installation: Includes a potentiometer for 270° adjustment and LED indicators for status monitoring.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Functional principle | Photoelectric proximity sensor | Functional principle detail | Energetic |
Dimensions (W x H x D) | 18 mm x 18 mm x 38.1 mm | Housing design (light emission) | Cylindrical |
Thread diameter (housing) | M18 x 1 | Optical axis | Axial |
Sensing range max. | 3 mm ... 115 mm | Sensing range | 5 mm ... 100 mm |
Type of light | Visible red light | Light source | PinPoint LED |
Light spot size (distance) | Ø 8 mm (100 mm) | Wave length | 650 nm |
Adjustment | Potentiometer, 270° | Indication_LED green | Operating indicatorStatic on: power on |
Indication_LED yellow | Status of received light beamStatic on: object presentStatic off: object not present | Supply voltage UB | 10 V DC ... 30 V DC |
Ripple | < 5 V | Current consumption | 30 mA |
Switching output | NPN | Output function | Complementary |
Switching mode | Light/dark switching | Output current Imax. | ≤ 100 mA |
Response time | < 1,000 µs | Switching frequency | 500 Hz |
Connection type | Cable, 4-wire, 2 m | Cable material | Plastic, PVC |
Circuit protection | A7)#!#B8)#!#D9) | Protection class | III |
Housing material | Plastic, ABS | Optics material | Plastic, PMMA |
Enclosure rating | IP67 | Items supplied | Fastening nuts (2 x) |
Electromagnetic compatibility (EMC) | EN 60947-5-2 | Ambient operating temperature | –25 °C ... +55 °C |
Ambient temperature, storage | –40 °C ... +70 °C | UL File No. | NRKH.E348498 & NRKH7.E348498 |
Specifications may be subject to change without notice
