Product Model
3KF3425-0MF11
Selling Points
- 1Handles up to 250 A, suitable for demanding electrical applications.
- 2Built to withstand heavy use, ensuring long-lasting performance.
- 3Protects against electric shock with permanent switch-on and switch-off under load.
- 4Available for floor mounting, standard rail mounting, and front mounting.
- 5Covered by a 12-month warranty from WiAutomation, with additional protection for non-compliant products.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
DC Insulation Voltage (V): | 220VDC/440VDC | AC Rated Voltage (V): | 690 |
Insulation Voltage (V): | 1000 | Description | 3KF LV HRC (General Fuse), rated current 250A, basic unit — front operation mechanism, no handle, operation mechanism module located at the center of the switch, surface mount |
Mounting Type: | Surface mount | Fuse Specification: | Size: 1 |
Terminal Type: | Flat terminal | Number of Poles: | 4P |
In(A): | 250 | Specification: | 3KF3_250 |
Switch Type: | Basic unit, front operation mechanism, no handle, operation mechanism module located at the center of the switch | Lifecycle | Delivery Release (PM300) |
Country of Origin | China | ECCN | N |
AL | N | Model Number | 3KF3425-0MF11 |
Specifications may be subject to change without notice
