Product Model
3NP1123-1JC20
Selling Points
- 1Handles up to 160A for reliable power distribution.
- 2Suitable for Rittal busbar systems with a cover level of 32/70 mm.
- 3Includes overvoltage protection monitoring and phase failure monitoring.
- 4Compatible with solid or stranded conductors from 1.5 mm² to 50 mm².
- 5Operates within a temperature range of -25°C to +55°C for robust performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
DC Insulation Voltage(V) | 440 | AC Rated Voltage(V) | 690 |
Insulation Voltage(V) | 1000 | Number of Poles | 3P |
Description | 3NP1, Rated current 160A, Size 000, 60mm Busbar System, Box Terminal, 3P, Suitable for Rittal Riline60 system with base | Others | Suitable for Rittal Riline60 system with base |
Installation Type | 60mm Busbar System | Fuse Rating | Size:000 |
Terminal Type | Box Terminal | Rated Current In(A) | 160 |
Specifications | 3NP112【160A】 | Lifecycle | Delivery Release (PM300) |
Country of Origin | Germany | ECCN | 9N9999 |
AL | N | Model Number | 3NP1123-1JC20 |
Specifications may be subject to change without notice
