Product Model
3NP1143-1JC23
Selling Points
- 1Handles continuous current up to 250 A.
- 2Equipped with electronic EFM20 for enhanced fuse monitoring.
- 3Suitable for Rittal busbar systems with a cover level of 32/70 mm.
- 4Busbar thickness options of 5 or 10 mm ensure durability.
- 5Offers protection against overvoltage and short circuits with IP40/30 ratings.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
DC Insulation Voltage(V) | 440 | AC Rated Voltage(V) | 690 |
Insulation Voltage(V) | 1000 | Number of Poles | 3P |
Description | 3NP1, Rated current 250A, Size 0/1, 60mm Busbar System, Box Terminal, 3P, Electronic EFM20 Fuse Monitoring, Suitable for Rittal Riline60 system with base | Other | Suitable for Rittal Riline60 system with base |
Fuse Monitoring | Electronic EFM20 Fuse Monitoring | Installation Type | 60mm Busbar System |
Fuse Rating | Size: 0/1 | Terminal Type | Box Terminal |
Rated Current In(A) | 250 | Specifications | 3NP114【250A】 |
Lifecycle | Delivery Release (PM300) | Country of Origin | Germany |
ECCN | 9N9999 | AL | N |
Model Number | 3NP1143-1JC23 |
Specifications may be subject to change without notice
