Product Model
3NP1153-1BC23
Selling Points
- 1Robust Protection: Designed to protect against electric shock with permanent switch-on and switch-off under load.
- 2Compact Design: Suitable for space-limited installations, ensuring efficient use of available space.
- 3High Current Rating: Handles up to 400 A, making it ideal for heavy-duty applications.
- 4Versatile Mounting Options: Compatible with floor mounting, busbar systems, and standard mounting rails.
- 5Comprehensive Accessories: Includes a range of accessories for enhanced functionality and customization.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
DC Insulation Voltage(V) | 440 | AC Rated Voltage(V) | 690 |
Insulation Voltage(V) | 1000 | Number of Poles | 3P |
Description | 3NP1, rated current 400A, Size 1/2, 60mm busbar system, box terminal, 3P, electronic EFM20 fuse monitoring, 32/70mm cover with contact protection, suitable for busbar and Rittal systems without base | Other | 32/70mm cover with contact protection, suitable for busbar and Rittal systems without base |
Fuse Monitoring | Electronic EFM20 Fuse Monitoring | Installation Type | 60mm Busbar System |
Fuse Rating | Size: 1/2 | Terminal Type | Box Terminal |
Rated Current In(A) | 400 | Specification | 3NP115【400A】 |
Lifecycle | Delivery Release (PM300) | Country of Origin | Germany |
ECCN | 9N9999 | AL | N |
Model Number | 3NP1153-1BC23 |
Specifications may be subject to change without notice
