Product Model
3NP1163-1JC21
Selling Points
- 1630A for reliable protection against short circuits and overloads.
- 2Space-saving design for easy installation in Rittal applications.
- 33-pole configuration for versatile use in electrical distribution systems.
- 4Electronic fuse monitoring for enhanced safety and reliability.
- 5Suitable for floor mounting and busbar systems, ensuring flexibility in installation.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
DC Insulation Voltage(V) | 440 | AC Rated Voltage(V) | 690 |
Insulation Voltage(V) | 1000 | Number of Poles | 3P |
Description | 3NP1, Rated current 630A, Size 2/3, 60mm Busbar System, Box Terminal, 3P, Electromechanical Fuse Monitoring, Suitable for Rittal Riline60 system with base | Other | Suitable for Rittal Riline60 system with base |
Fuse Monitoring | Electromechanical Fuse Monitoring | Installation Type | 60mm Busbar System |
Fuse Rating | Size: 2/3 | Terminal Type | Box Terminal |
Rated Current In(A) | 630 | Specifications | 3NP116【630】 |
Lifecycle | Delivery Release (PM300) | Country of Origin | Germany |
ECCN | 9N9999 | AL | N |
Model Number | 3NP1163-1JC21 |
Specifications may be subject to change without notice
