Product Model
3RT5045-1AB00
Selling Points
- 1High Power Handling: Handles up to 37 kW at 400 V, making it suitable for demanding industrial applications.
- 2Reliable Operation: Meets AC3 standards for reliable operation in harsh environments.
- 3Compact Design: Features a compact S3 screw terminal design for easy installation and space efficiency.
- 4Wide Compatibility: Compatible with 24 V AC and 50 Hz, ensuring broad application flexibility.
- 5Compliance with Regulations: Compliant with RoHS directive since 2017 and WEEE take-back obligations.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Main Contact Configuration | 3NO | Wiring Method | Screw Terminal |
Auxiliary Contacts | None | Coil Frequency | 50HZ |
Coil Power Supply | AC | Number of Poles | 3P |
Rated Current AC-3 | 80A | Specification | S3 |
Product Type | Contactor | Lifecycle | Delivery Release (PM300) |
Country of Origin | China | ECCN | N |
AL | N | Model Number | 3RT5045-1AB00 |
Specifications may be subject to change without notice
