Product Model
3VA1463-1AA32-0AA0
Selling Points
- 1Handles up to 630A without overload protection.
- 2Meets international standards for electrical equipment.
- 3Suitable for various electrical configurations and applications.
- 4Ensures reliable operation in harsh environments.
- 5Easy to integrate into existing electrical panels.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Rated Voltage(V): | 690 | Number of Poles: | 3P |
Description | 3VA1B630 R630 SD100 F/3P; 3VA1_630 dimensions; Rated current 630A; Breaking B: 16kA; Trip unit SD100; | Mounting Method: | F: Fixed |
Trip Unit: (If required is not in the list, reset and select trip unit first) | SD100【Isolator Switch】 | Breaking Rating: | (Isolation) |
Rated Current In(A): | 630 | Specifications: | 630【400-630A】 |
Lifecycle | Delivery Release (PM300) | Country of Origin | Germany |
ECCN | 9N9999 | AL | N |
Model Number | 3VA1463-1AA32-0AA0 |
Specifications may be subject to change without notice
