Product Model
3VA2325-6HL32-0AA0
Selling Points
- 1High breaking capacity with Class H rating.
- 2Advanced electronic trip unit (ETU320) for precise protection.
- 3250A 3-pole design with 85 kA Icu at 415 V.
- 4Overload protection up to 100 A.
- 5Reliable line protection for industrial settings.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Rated Service Breaking Capacity Ics(kA):@400V or 415V | 85 | Rated Voltage(V): | 690 |
Number of Poles: | 3P | Description | 3VA2H400 R250 ETU320 F/3P; 3VA2_400 Size; Rated Current 250A; Interrupting Rating H:85kA; Trip Unit ETU320; |
Mounting Method: | F: Fixed | Trip Unit: (If required is not in the list, reset and select trip unit first) | ETU320【Electronic Type LI】 |
Rated Ultimate Breaking Capacity Icu(kA):@400V or 415V | 85 | Interrupting Rating: | H:85kA |
Rated Current In(A): | 250 | Specification: | 400【250-400A】 |
Lifecycle | Delivery Release (PM300) | Country of Origin | China |
ECCN | 9N9999 | AL | N |
Model Number | 3VA2325-6HL32-0AA0 |
Specifications may be subject to change without notice
