Product Model
3VM9114-0SS10
Selling Points
- 1Compact Design: The 3VM9114-0SS10 features a compact design with a mounting depth of 70 mm, ideal for protecting cables and lines in plant areas.
- 2Modular Accessories: Equipped with a universal platform of modular and easy-to-fit internal accessories, enhancing flexibility and reducing installation time.
- 3Thermal-Magnetic Trip Units: Utilizes thermal-magnetic trip units for reliable overload and short-circuit protection, suitable for three-phase AC networks and DC applications.
- 4Wide Operational Range: Available in various sizes (100 A, 160 A, 250 A, 400 A, and 630 A) with rated operational currents from 16 A to 630 A and rated voltages up to 500 V.
- 5Compliance with International Standards: Meets the requirements of IEC / EN 60947-1, IEC / EN 60947-2, and other relevant standards for electromagnetic compatibility and safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Packaging Quantity | 1 | Quantity Unit | 1 Piece |
Package size unit of measure | MM | Packaging Dimension | 150,00 x 200,00 x 30,00 |
Net Weight (kg) | 0,037 Kg | Estimated dispatch time (Working Days) | 20 Day/Days |
Export Control Regulations | AL : N / ECCN : N | Notes | Please enter text for every Y option (using the Configurator). |
Product Lifecycle (PLM) | PM300:Active Product | Product family | Actuators and indicators, 22 mm, round, plastic, black |
Product Description | Indicator lights, 22 mm, round, plastic, red, lens, smooth, with holder, LED module, with integrated LED 230 V AC, screw terminal, with laser labeling, inscription or symbol Customer-specific selection with SIRIUS ACT configurator (CIN) | Article Number (Market Facing Number) | 3SU1106-6AA20-1AA0-Z Y19 |
Specifications may be subject to change without notice
