Product Model
5SN3006-7CN
Selling Points
- 1High torque output of 30Nm (100K) for efficient operation.
- 2Compact design with recessed flange for space-saving installations.
- 3Advanced temperature control with Pt1000 temperature sensor.
- 4Integrated absolute encoder EnDat 2048 S/R for precise positioning.
- 5Special shaft with external gearing for customized applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Installation Module | 1 | Specification | 5SN3【6-40A】 |
Number of Poles | 1P+N | Trip Unit | C【C characteristic curve】 |
Breaking Capacity Icn(kA) per IEC60898 Standard | 4.5 | Rated Current In(A) | 6 |
Lifecycle | Delivery Release (PM300) | Country of Origin | China |
ECCN | N | AL | N |
Model Number | 5SN3006-7CN |
Specifications may be subject to change without notice
