Product Model
6SL3220-3YD58-0CB0
Selling Points
- 1355 kW at 135% for 3 seconds, 110% for 60 seconds, and 100% for 240 seconds.
- 2Integrated class C3 filter for category C3 applications.
- 3Operates at 380 to 440 V with a ±10% tolerance.
- 4Supports V/f linear, square-law, and parameterizable control methods.
- 5IP20/UL open type degree of protection and robust mechanical design.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Depth | 393mm | Height | 1,487mm |
Width | 548mm | Analog Outputs | 2 |
Analog Inputs | 2 | Digital Outputs | 4 |
Digital Inputs | 6 | Protection Rating | IP20 |
Dimensions | FSH | Input Phases | 3 |
Filter | Integrated A-C3 Class Filter | Motor Power | 355kW |
Rated Voltage | 380-440V | Product Type | Inverter |
Lifecycle | Delivery Release (PM300) | Country of Origin | China |
ECCN | 3A999A | AL | N |
Model Number | 6SL3220-3YD58-0CB0 |
Specifications may be subject to change without notice
