Product Model
BPZ:QAE2174.010
Selling Points
- 1High precision temperature measurement with ±1 K accuracy in the range of 0…70 °C.
- 2Reliable performance with a time constant of 30 seconds and a temperature measuring range of -10…120 °C.
- 3Compatible with 4…20 mA signal output and operating voltage of DC 13.5…35 V.
- 4Durable construction with stainless steel immersion pocket and screw terminals for secure connections.
- 5Easy installation with a G ½" connecting thread and IP54 protection rating for harsh environments.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Dimensions (Width x Height x Length) | 80 x 88 x 39 mm | Connection Method | Threaded Connection |
Installation Method | Protection Sleeve G½" | Measurement Accuracy | At 0…70 °C: ±1 K |
Operating Voltage | DC 13.5...35 V | Lifecycle | P.M300 |
Country of Origin | China | ECCN | 9N9999 |
AL | N | Model | BPZ:QAE2174.010 |
Specifications may be subject to change without notice
