Product Model
279-316
Selling Points
- 1Made from 2 mm thick polyamide (PA66) for enhanced insulation and durability.
- 2Compliant with 0.099 MJ fire load, ensuring safety in high-temperature environments.
- 3Dimensions of 2.669 in H x 0.079 in W x 1 in D, ideal for space-constrained applications.
- 4Suitable for use with rail-mounted terminal blocks, offering flexibility in electrical connections.
- 5Meets RoHS compliance standards, ensuring environmental sustainability and regulatory adherence.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 2?mm?/ 0.079?inches | Height | 67.8?mm?/ 2.669?inches |
Depth | 25.4?mm?/ 1?inches | Note (material data) | Information on material specifications can be found here |
Color | gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.146MJ | Weight | 3.3g |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4017332295017 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
