Product Model
280-322
Selling Points
- 1The WAGO 280-322 terminal block features automatic clamping technology, ensuring secure connections without manual adjustment.
- 2Designed to withstand high pull-out forces, this terminal block provides reliable connections even under stress.
- 3Built with high-quality materials, including polyamide (PA66) insulation, for long-lasting performance.
- 4Simple and quick installation process, reducing setup time and increasing productivity.
- 5Compatible with various conductor sizes, from AWG 28 to 35 mm², making it versatile for different applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 2?mm?/ 0.079?inches | Height | 48?mm?/ 1.89?inches |
Depth | 32?mm?/ 1.26?inches | Note (material data) | Information on material specifications can be found here |
Color | orange | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.081MJ | Weight | 2.5g |
Processing temperature | -35 … +85?°C | Continuous operating temperature | -60 … +105?°C |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4017332297745 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
