Product Model
280-907/999-950
Selling Points
- 1Compact design for three phases and one ground conductor in a single terminal block.
- 2High reliability with automatic clamping mechanism for secure connections.
- 3Easy installation with minimal wire preparation required.
- 4Suitable for a wide range of applications including industrial and commercial settings.
- 5Meets international safety standards with approvals available at www.wago.com.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Clamping units | 2 | Total number of potentials | 1 |
Number of levels | 1 | Width | 5?mm?/ 0.197?inches |
Height | 54?mm?/ 2.126?inches | Depth from upper-edge of DIN-rail | 28?mm?/ 1.102?inches |
Design | horizontal type | Mounting type | DIN-35 rail |
Marking level | Center marking | Note (material data) | Information on material specifications can be found here |
Color | green-yellow | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.09MJ | Weight | 9.2g |
Processing temperature | -35 … +85?°C | Continuous operating temperature | -60 … +105?°C |
eCl@ss 10.0 | 27-14-11-41 | eCl@ss 9.0 | 27-14-11-41 |
ETIM 9.0 | EC000901 | ETIM 8.0 | EC000901 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 100?pcs |
Packaging type | box | Country of origin | DE |
GTIN | 4045454108144 | Customs tariff number | 8536904000 |
CAS-No. | 7439-92-1 | REACH Candidate List Substance | Lead |
RoHS Compliance Status | Compliant,No Exemption | SCIP notification number (Austria) | d14e543b-05fe-4bc6-9375-cfdb87d236b7 |
SCIP notification number (Belgium) | 8c95777f-ddc6-47eb-80f7-935c72b56294 | SCIP notification number (Bulgaria) | 7f4ae827-e1fe-40e9-b793-f5bc1aaa6ce3 |
SCIP notification number (Czech Republic) | 5c6f59a5-2915-440d-9aa0-0c2decbed6e4 | SCIP notification number (Denmark) | df97c799-5bd6-4978-a327-b8f2accd53d4 |
SCIP notification number (Finland) | a6e5c966-754f-4182-8f5e-035634d89dc8 | SCIP notification number (France) | 23eaec2d-2aa2-4189-b258-b9f32d6fc76e |
SCIP notification number (Germany) | 28bd4545-10b9-474a-8591-df2b8d048af3 | SCIP notification number (Hungary) | 09763eb5-07b0-44ee-a8c0-24ea210b67cf |
SCIP notification number (Italy) | 0abfa0c1-2c3d-4599-aabd-ed69fef609fa | SCIP notification number (Netherlands) | 31fbd689-d71e-4f7a-a781-b59b5a30b0a8 |
SCIP notification number (Poland) | 123fe025-d67c-4a40-ad4c-ae5217129361 | SCIP notification number (Romania) | 2924a088-88fd-4eeb-b5fb-a73222dc23c7 |
SCIP notification number (Sweden) | 23644f9c-197e-4771-9f80-f0063badd610 | Ratings per | IEC/EN 60947-7-2 |
Reference hazardous areas | See application instructions in section “Knowledge andDownloads – Documentation – Additional Information: Technical Section; Technical Explications” | Connection technology | CAGE CLAMP? |
Actuation type | Operating tool | Connectable conductor materials | Copper |
Solid conductor | 0.08 … 2.5?mm2?/ 28 … 12?AWG | Fine-stranded conductor | 0.08 … 2.5?mm2?/ 28 … 12?AWG |
Note (conductor cross-section) | 12 AWG: THHN, THWN | Strip length | 8 … 9?mm?/ 0.31 … 0.35?inches |
Wiring direction | Front-entry wiring |
Specifications may be subject to change without notice
