Product Model
281-312
Selling Points
- 1Made from 2.5 mm thick material for long-lasting durability.
- 2Designed for seamless integration with WAGO rail-mounted terminal blocks.
- 3Ensures secure connections and reduces the risk of electrical faults.
- 4Compatible with various WAGO terminal block series, including TOPJOB S and Series 2001.
- 5Gray finish for easy identification and integration into your electrical setup.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 2.5?mm?/ 0.098?inches | Height | 61?mm?/ 2.402?inches |
Depth | 37?mm?/ 1.457?inches | Note (material data) | Information on material specifications can be found here |
Color | gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.08MJ | Weight | 2.7g |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | CN | GTIN | 4017332292573 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
