Product Model
281-324
Selling Points
- 1High-Quality Construction: 2.5mm thick, durable gray plate for reliable performance.
- 2Versatile Compatibility: Suitable for use with rail-mounted terminal blocks, ensuring seamless integration.
- 3Enhanced Fire Load Resistance: 0.122 MJ fire load, providing superior safety in industrial settings.
- 4Compact Dimensions: 1.142 in H x 0.09 in W x 2.88 in D, perfect for space-efficient installations.
- 5RoHS Compliant: Meets environmental standards, ensuring eco-friendly operations.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 2.5?mm?/ 0.098?inches | Height | 73.2?mm?/ 2.882?inches |
Depth | 27.2?mm?/ 1.071?inches | Note (material data) | Information on material specifications can be found here |
Color | gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.122MJ | Weight | 4.1g |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | CN | GTIN | 4017332292580 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
