Product Model
281-673/281-411
Selling Points
- 1Securely connects conductors up to 4 mm².
- 2Prevents electrolytic corrosion between aluminum and copper conductors.
- 3Compatible with DIN-rail 35 x 15 and 35 x 7.5.
- 4Supports up to 0.5 A of current.
- 5Simplifies wiring with easy front-entry connections.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Clamping units | 3 | Total number of potentials | 1 |
Number of levels | 1 | Width | 6?mm?/ 0.236?inches |
Height | 73.5?mm?/ 2.894?inches | Depth from upper-edge of DIN-rail | 29?mm?/ 1.142?inches |
Design | horizontal type | Mounting type | DIN-35 rail |
Marking level | Center marking | Note (material data) | Information on material specifications can be found here |
Color | gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.189MJ | Weight | 11.4g |
Processing temperature | -35 … +85?°C | Continuous operating temperature | -60 … +105?°C |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-27 |
eCl@ss 9.0 | 27-14-11-27 | ETIM 9.0 | EC000903 |
ETIM 8.0 | EC000903 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 50?pcs | Packaging type | box |
Country of origin | CN | GTIN | 4050821275596 |
Customs tariff number | 8536904000 | CAS-No. | 7439-92-1 |
REACH Candidate List Substance | 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol | RoHS Compliance Status | Compliant,With Exemption |
RoHS Exemption | 7(a) | SCIP notification number (Austria) | ae67f2d8-f67f-4152-98f6-f576a1a5b477 |
SCIP notification number (Belgium) | 572417b8-ef78-46dd-a48e-8b0541f26941 | SCIP notification number (Bulgaria) | fde16b0a-b1ef-4852-9077-e2c9c7f58276 |
SCIP notification number (Czech Republic) | f6300d7f-5dd9-4957-9d1e-0d9b895f2364 | SCIP notification number (Denmark) | d1712688-5410-44e5-b37d-2cffa3245caf |
SCIP notification number (Finland) | 0c36a0d0-af38-4ff8-9dae-a8d2d86dd809 | SCIP notification number (France) | 6881a1bf-5555-4589-b693-bf77099fe51e |
SCIP notification number (Germany) | 082e8253-3f1f-4b00-9d59-815c2556d43b | SCIP notification number (Hungary) | b028ef72-e1e0-4cfe-a241-15fbd19aa033 |
SCIP notification number (Italy) | 5bb8ba34-8856-44be-a085-89f29293626f | SCIP notification number (Netherlands) | aae763a1-6902-4909-9710-e6b174923fe1 |
SCIP notification number (Poland) | 051f60bd-af19-41b3-bd85-347947eea9f2 | SCIP notification number (Romania) | 66f696c3-01c8-4675-bcf7-6bf0bfcba7a3 |
SCIP notification number (Sweden) | e12a92ff-5557-411a-8619-9ef2be87be28 | Ratings per | IEC/EN 60947-7-1 |
Rated current | 0.5A | Nominal voltage | 250V |
Reverse voltage | 1,000V | Connection technology | CAGE CLAMP? |
Actuation type | Operating tool | Connectable conductor materials | Copper |
Connectable conductor materials (note) | Terminating Aluminum ConductorsWAGO Spring-Clamp Terminal Blocks are suitable for solid aluminum conductors up to 4 mm2/12 AWG if WAGO “Alu-Plus” Contact Paste249-130is used for termination.“Alu-Plus” Contact Paste Advantages:Automatically destroys the oxide film during clamping.Prevents fresh oxidation at the clamping point.Prevents electrolytic corrosion between aluminum and copper conductors (in the same terminal block).Provides long-term protection against corrosion.Using terminal blocks with CAGE CLAMP?Spring Pressure Connection Technology,aluminum conductors must first be cleaned with a bladeand then immediately inserted into the clamping units filled with “Alu-Plus” contact paste.It is also possible to apply WAGO “Alu-Plus”additionallyon the whole surface of the aluminum conductor before termination.Please note that the nominal currents must be adapted to the reduced conductivity of the aluminum conductors::2.5 mm2 = 16 A4 mm2 = 22 A | Solid conductor | 0.08 … 4?mm2?/ 28 … 12?AWG |
Fine-stranded conductor | 0.08 … 4?mm2?/ 28 … 12?AWG | Strip length | 9 … 10?mm?/ 0.35 … 0.39?inches |
Wiring direction | Front-entry wiring |
Specifications may be subject to change without notice
