Product Model
283-317
Selling Points
- 1Compact Design: 3.15 in H x 0.157 in W x 21.476 in D dimensions for easy installation.
- 2High Fire Load: 0.22 MJ fire load ensures reliable performance in demanding environments.
- 3Rail Mount Compatibility: Specifically designed for use with rail-mounted systems.
- 4Orange Color: Easy identification with an orange color.
- 5RoHS Compliant: Meets environmental standards for safe and sustainable use.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 4?mm?/ 0.157?inches | Height | 80?mm?/ 3.15?inches |
Depth | 37.5?mm?/ 1.476?inches | Note (material data) | Information on material specifications can be found here |
Color | orange | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.22MJ | Weight | 7.3g |
Processing temperature | -35 … +85?°C | Continuous operating temperature | -60 … +105?°C |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 50?(25)?pcs | Packaging type | box |
Country of origin | CN | GTIN | 4017332286435 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
