Product Model
289-449
Selling Points
- 1High-Reliability Connectivity: Designed for industrial applications with a 50-pole D-subminiature male connector.
- 2Vertical Mounting: Easy installation on DIN rail with mounting feet.
- 3Double-Row PCB Terminal Blocks: Efficient connection management with solder pins.
- 4Operational Range: Compatible with -20°C to +50°C ambient temperature and up to 85% relative humidity.
- 5Durable Construction: Constructed with Au over Ni contacts for long-lasting performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Operating voltage | ≤30?VAC;?≤50?VDC | Nominal current | 1A |
Contact resistance (max.) | 30?mΩ | Rated voltage | 50V |
Rated surge voltage | 0.8kV | Pollution degree | 2 |
Protection type | IP00;Notice!Live parts can be easily touched! Protection against direct contact must be provided by the equipment manufacturer, e.g., using a WAGO 709 Series Cover (see “Accessories”) or a similar cover. The installation guidelines must be observed for each individual application. | Insulation type | Basic insulation |
Performance level | 2 / 200 mating cycles | Strain relief | UNC 4-40 stud bolt |
Width | 157?mm?/ 6.181?inches | Height | 63.5?mm?/ 2.5?inches |
Depth from upper-edge of DIN-rail | 19?mm?/ 0.748?inches | Mounting type | DIN-35 rail |
Housing design | PCB with mounting feet | Contact material (connector) | Au over Ni |
Fire load | 0.084MJ | Weight | 98.7g |
Ambient temperature (operation) | -20 … +50 °C | Ambient temperature (storage) | -40 … +70 °C |
Relative humidity | 85% (non-condensing) | Standards/specifications | EN 61010-2-201 |
Product Group | 6 (INTERFACE ELECTRONIC) | eCl@ss 10.0 | 27-14-11-52 |
eCl@ss 9.0 | 27-14-11-52 | ETIM 9.0 | EC002780 |
ETIM 8.0 | EC002780 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 5?(1)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4045454599423 |
Customs tariff number | 8536904000 | CAS-No. | 7439-92-1 |
REACH Candidate List Substance | Lead | RoHS Compliance Status | Compliant,With Exemption |
RoHS Exemption | 6(c) | SCIP notification number (Austria) | f37bd52d-cd1e-4a17-8b6f-4b4aab35e041 |
SCIP notification number (Belgium) | 8f5f0157-2460-42b1-8f0e-e973920c5ac9 | SCIP notification number (Bulgaria) | a1fe57e8-c7e2-4083-ad37-f47ff4a9b3d0 |
SCIP notification number (Czech Republic) | 3115decb-3499-4b66-a6c3-d2f3c8ad1a7d | SCIP notification number (Denmark) | 3d5644c9-b42c-41b9-b0c8-bad9387248b9 |
SCIP notification number (Finland) | 02548901-7b45-497a-accb-3a0379fbeba7 | SCIP notification number (France) | 0b73c2fc-5523-44c2-8420-28a35cc9775b |
SCIP notification number (Germany) | 1564835a-eec6-4b59-adf1-f87a59435c4a | SCIP notification number (Hungary) | 07e198eb-8d32-4ba2-b773-df9dffa3cd08 |
SCIP notification number (Italy) | fb299edc-3755-44b5-8273-50a52b8b570f | SCIP notification number (Netherlands) | c5fc6a9b-d5ea-447b-a257-26191caee825 |
SCIP notification number (Poland) | 50d0a6f1-89ad-4ce5-bc92-c2911bd5eada | SCIP notification number (Romania) | c4d4ffbd-ec01-4af8-a497-6d5498258bc7 |
SCIP notification number (Sweden) | e806ae4d-101d-44aa-9e74-645a0094d4fc | Pluggable connector | D-subminiature male connector |
Pole number 1 | 50 | Connection type 1 | System |
Note (conductor cross-section) | 12 AWG: THHN, THWN | Mating direction | vertical |
Design 2 | PCB terminal blocks (double-row) | Pole number (2) | 50 |
Connection type 2 | Field | Connection technology 2 | CAGE CLAMP? |
WAGO connector 2 | WAGO 236 Series | Solid conductor 2 | 0.08 … 2.5?mm2?/ 28 … 12?AWG |
Fine-stranded conductor 2 | 0.08 … 2.5?mm2?/ 28 … 12?AWG | Strip length 2 | 5 … 6?mm?/ 0.2 … 0.24?inches |
Specifications may be subject to change without notice
